Sharaxaada Alaabta
ILI2510 Shaashadda Taabashadda Awoodda 10.1 Inj
isbarbardhigga xuduudaha alaabta
| Magaca alaabta |
ILI2510 Shaashadda Taabashadda Awoodda 10.1 Inj |
Summada |
Grahowlet |
| Qaabka alaabta | HX1011803 | Cabbirka | 10.1 inji |
| Heerkulka shaqada | -20 darajo ~70shahaadada , In ka yar ama la mid ah 85% RH | Xakamaynta IC | Cypress |
| Heerkulka Kaydinta | -30darajo ~80shahaadada , In ka yar ama la mid ah 85% RH | Dhibcaha taabashada | 10 dhibcood |
| Cabirka dulucda | 229.46 (W)×149.10(H)×2.10(D)mm | Qaraarka | 800×1280 |
| Aagga Daawashada | 217.56 (W)×136.20(H)mm | Shaqada isku xidhka | Isku xidhka hawada/ indhaha |
| Korantada Supply | 2.8V~3.3V | Codsiga | Codsiga Warshadaha |
| Nidaamka Taageerada | Windows/Android/Linux iwm. | Nooca Interface | IIC/USB |
| Dammaanad | 1 sano | Qaab dhismeedka | G+G |
| Hufnaan | Ka weyn ama la mid ah 85% | Adagnaanta Dusha |
Ka weyn ama la mid ah 6H |
10 - TAAGEERO DHIIQ AH OO TABAAB BADAN
Khibrad u yeelo bilaa-jawaab la'aan, jawaabo badan oo badan{0}}Aqoonsiga gacanta faraha oo sax ah 10{3}} tignoolajiyada taabashada awooda leh. Haddi la jiido si loo soo dhaweeyo, sawiro wareega, ama fulinta amarrada gacanta ee isku dhafan, qaybtan soobandhiga ahi waxa ay keentaa is dhexgal aan habsaamin, kaas oo kor u qaadaya wax soo saarka iyo ka qaybgalka isticmaale ee dhammaan codsiyada.
HAWLGALKA TAABASHADA BIYAHA IYO CUSBADA
Waxaa loo farsameeyay si uu u guto si aan cillad lahayn marka lagu jiro xaaladaha qoyan iyo qoyan, qaybtan taabashada awoodda leh ayaa ilaalinaysa ogaanshaha taabashada saxda ah xitaa marka dusha sare ee shaashadda lagu daboolo biyo, roob, ama buufin biyaha cusbada ah. Ku habboon nidaamyada socodka badda, dukaamada bannaanka, dhirta cuntada lagu sameeyo, iyo deegaan kasta oo qoyaanka soo-gaadhista aan laga fursan karin.
GLOVE UNIVERSAL -TECHNOLOGY TABASHADA SAXIIBIGA AH
Taabasho taabasho{0}iyada oo{1}}awoodda gacan-gashigu waxay taageertaa galoofyada agabka oo dhan. Habkani wuxuu meesha ka saarayaa baahida loo qabo dadka isticmaala inay ka saaraan qalabka ilaalinta, hubinta socodka shaqada ee aan kala go'a lahayn ee warshadaha, shaybaarada, xarumaha kaydinta qabowga, iyo goobaha shaqada ee dibadda.
HUFAN ARAGTIDA SARE (Ka weyn ama la mid ah 85%)
Ku raaxayso muraayada{0} muuqaal cad oo leh warshado{1}} hufnaanta indhaha ee hogaaminaysa 85% ama ka sareeya. Tani waxay hubinaysaa in ay muujinayso nuxurka{4} hadday tahay qoraal, garaafyo, ama muuqaal -u muuqdo firfircoon, iyo run{6}}midab -, kor u qaadaysa wax akhrinta iyo yaraynta culayska indhaha inta lagu jiro isticmaalka dheeraanta.
Hangzhou Hongxiao Technology Co., Ltd. waa -heer sare{3} shirkad teknooloji ah oo xarunteedu tahay Hangzhou, oo haysata in ka badan 30 shahaado oo ay ku jiraan shatiyada hal abuurka iyo xuquuqda daabacaadda software. Shirkaddu waxay ugu horreyn ku hawlan tahay cilmi-baarista, horumarinta, wax-soo-saarka, iyo iibinta muraayadaha taabashada awoodda leh, bandhigyada LCD, modules-yada taabashada awoodda leh, muraayadaha dekedaha taxan ee warshadaha, qaybaha taabashada si buuxda loo daboolay, looxyada darawallada interface, iyo qaybaha dhismaha. Shirkaddu waxay ku shaqeysaa qalab wax soo saar casri ah oo casri ah oo loogu talagalay alaabo -mashiinka is dhexgalka mashiinka. Qaybaheeda taabashada awoodda leh waxaa loo dhoofiyaa kumanaan macaamiisha adduunka oo dhan waxaana si weyn loogu isticmaalaa meelaha sida aaladaha caafimaadka, codsiyada baabuurta, xakamaynta warshadaha, saldhigyada dallaca, nidaamyada guriga smart, qalabka smart, amniga smart, waxbarashada smart, iyo robotics smart. Iyadoo waayo-aragnimo ballaadhan u leh warshadaha{10} xalalka mashruuca gaarka ah, shirkaddu waxay awood u leedahay inay siiso xirfadle, xalal la habeeyey iyo adeegyo farsamo macaamiisha qaybaha kala duwan.
01
Khibrad qani ah
Iyada oo in ka badan 10 sano oo khibrad warshadeed ah, shirkaddeenu waxay u dejisay itseif sidii hogaamiye lagu kalsoon yahay xagga nakhshadeynta, horumarka, iyo soo saarista muraayadaha taabashada awoodda leh ee sare-
02
Mashiino Hormarsan
Xoog warshad isku dhafan si ay u taageeraan dhammaan noocyada kala duwan ee taabashada taabashada capacitive, oo leh substrate galaas, flim salka, xabagta indhaha (OCA), ITO daahan dhammaan awoodda wax soo saarka alaabta ceeriin.
03
Farsamooyin heer sare ah
Waxaan bixinaa xalal taabasho ah oo la saadaalinayo- oo taageeraya taabasho badan, gacan-gashi, iyo isticmaalka adag{2}} Dib u habeynta OEM/ODM oo buuxa tignoolajiyadayadu waxay hubisaa saxnaanta, adkeysiga, iyo khibradda isticmaale ee heer sare ah ee warshadaha, caafimaadka iwm.
04
Adeegga gaarka ah
Waxaan bixinaa adeeg dhameystiran oo OEM/ODM ah oo loogu talagalay muraayadaha taabashada awoodda leh - laga bilaabo xulashada alaabta ceeriin (qalabka dhalada, dahaadhka ITO, isku xidhka OCA) ilaa naqshadaynta qaabdhismeedka, hagaajinta firmware, iyo la qabsiga deegaanka.
| Qiimaynta mashruuca | 1-2 maalmood oo shaqo ah |
| Naqshadaynta | 2-3 maalmood oo shaqo ah |
| Alaabta gaarka ah | 3 ~ 4 usbuuc (ka dib markii sawirada la ansixiyay) |
| Gaadhsiinta Wax-soo-saarka Mass | 4.3-5 toddobaad |
| Awood | 100k bishii (10.1inji tixraac ahaan) |
| awoodda farsamada | G+G/G+F+F, habka gaashaandhigga oo buuxa Lamination (OCR/OCA), Dabool daawaynta dusha dhalada ah sida AR,AG,AP, iwm. |
| Taageerada Farsamada | Injineeradu waxay ku bixiyaan albaab- - albaab ama adeegyo gelitaanka fog 24 saacadood gudahood |
| Silsilad sahayd deggan oo dammaanad ah ugu yaraan 3 ilaa 5 sano | |
| Hal -Dammaanad ah dhammaan alaabtayada | |
Shirkadeena waxay ku siinaysaa macluumaadka qaab dhismeedka iyo tafaasiisha la habeyn karo ee module bandhig taabasho karti leh oo la saadaaliyay, oo lakab ahaan loo kala jajabiyay:
1. Burburka lakabka (kor ilaa hoos)
◦ Muraayadaha Dabool: Lakabka difaaca ugu fog ee muraayadda taabashada.
◦ Dareemka: Taabasho{0}Lakabka xasaasiga ah ee ogaanaya gelinta isticmaalaha.
Shaashadda TFT: Shaashadda dareeraha ah ee soo saarta wax-soo-saarka muuqaalka.
◦ Tcon Board (Guddiga Xakamaynta Wakhtiga): Boodhka darawalka ee socodsiiya calaamadaha oo wada guddida bandhigga.
2. Faahfaahinta gaarka ah
◦ PCAP (Cover Glass + Touch Sensor):
◦ Cabbirka, taabashada IC, Qaabka, Midabka, Logo, Dhumucda, Interface, Qaab dhismeedka, FPC (Daabacan Dabacsan), Daaweynta Dusha, Heerkulka Shaqada
◦ TFT/OLED Panel Muqaal:
◦ Qaraarka, Iftiinka, Interface, Sumadda
◦ Tcon Board:
◦ HDMI/VGA-dareewalka, looxa buundada "IIC TO USB", Beddelka TFT, Shaashadda Serial Port.
Shirkaddayadu waxay macaamiisheena siisay dulmar tifaftiran oo ku saabsan qaybaha, astaamaha, iyo agabka qaybta shaashadda taabashada (TFT Bonded CTP):
1. Burburinta qaybaha
◦ Module Screen Touch (TFT Bonded CTP): Cutubka bandhiga taabashada oo si buuxda la isugu keenay.
◦ Muraayada Daboolka (Muraayada Daboolka):
◦ Astaamaha: Qaabab aan caadi ahayn oo la jarjaray oo la heli karo; waxay taageertaa daabacaadda xariirta iyo summada gaarka ah; ku habboon noocyada muraayadaha sida AGC, Corning, CG; waxaa lagu daawayn karaa AG (Anti{0}}Glare), AR (Anti-Reflective), AF (Ka-hortagga-Fingerprint), ama lidka - dahaarka qarxa; fursadaha dhumucdiisuna waa 0.55mm ilaa 6.0mm.
◦ Dareemaha taabashada:
◦ Astaamaha: Qalabka waxaa ka mid ah dhalo, filim, iyo filim -ku yaal-filim; dhumucda 0.005mm ilaa 1.1mm; qaababka FPC la beddeli karo; waxay taageertaa taabashada noocyada IC sida Cypress, Atmel Focaltech, Goodix, iyo EETI; Interfaces waxaa ka mid ah IIC, USB, SPI, iyo RS232.
◦ TFT LCD Muqaal: Shaashadda hoose ee shaashadda.
◦ Golaha: Waxaa lagu heli karaa iyada oo loo marayo Bonding Optical (OCA/OCR) ama hababka Adhesion Frame.
2. Macluumaad Dheeraad ah
◦ Haddii aad rabto interface USB, waxaan IIC ku siin karnaa buundada USB.
Sharaxaada Alaabta
Tilmaamaha Alaabta ee Bandhigga Taabashada
Sawirkaani wuxuu qeexayaa waxqabadka furaha ah iyo astaamaha is-beddelka ee moduleka bandhigga taabashada, oo leh sharraxaad sidan soo socota:
1. Waafaqid Taabasho Gacan-gashi
Shaashadda taabashada waxay taageertaa gelinta taabashada saxda ah iyada oo loo marayo galoofyada agabka oo dhan, xitaa leh dhumuc iskudar ah oo ilaa 6mm ah.
Noocyada gacan-gashiga ee la taageeray waxaa ka mid ah:
• galoofyada nylon/ galoofyada caaga ah/gacan-gashiga cudbiga ah/ galoofyada dhogorta ah/ galoofyada barafka
2. Biyo/Brine/Saliid u adkaysiga taabashada
Shaqada taabashada waxay ahaanaysaa mid la isku halayn karo marka shaashadu soo baxdo ama lagu shaqeeyo:
• Biyo saafi ah/saliid/ 5% biyo milix ah (brine)
3. 8mm Qarx qaro weyn{1}}Caddaynta Muraayada Daboolka
Bandhigu waxa lagu qalabayn karaa 8mm muraayad daboolan oo qaro weyn, oo bixisa iska caabin sare oo saamayn leh iyo qaraxa{1} waxqabadka caddaynta, iyadoo la ilaalinayo shaqaynta taabashada caadiga ah.
4. Daawaynta Dusha Muraayadaha Daboolka Ikhtiyaarka ah (AG, AR, AF)
Muraayadda daboolku waxay taageertaa saddex nooc oo dahaarka shaqaynaysa si kor loogu qaado waayo-aragnimada isticmaale iyo adkeysiga:
• Dawaynta Ka-hortagga-Glare (AG)
U beddelaa iftiinka tooska ah iftiinka fidsan ee muraayadda taabashada, baabi'inta muraayadda{0}sida milicsiga iyo yaraynta dhaldhalaalka.
• Dawaynta Ka-hortagga ah{{0}(AR)
Wuxuu ku daraa dahaarka si uu u yareeyo iftiinka iftiimaya ee muraayadda daboolka, hoos u dhigaya milicsiga muraayadda iyo hagaajinta muuqaalka iftiinka qorraxda.
• Dawaynta Ka-hortagga{{0}Fingerprint (AF).
Codsada dahaarka si ay u kordhiyaan simannaanta dusha, yaraynaysaa caabbinta simbiriirixan, calamadaha biyaha hadhaaga ah, iyo faraha faraha. Tani waxay hagaajinaysaa dareenka taabashada iyo caddaynta muuqaalka labadaba.
Shahaado
Shaashashooyinka taabashada awooda leh waxay kasbadeen foomka dib u eegista cayriin ee coustomer ee aduunka oo dhan, oo leh qiimeynta 5-xiddig ee joogtada ah oo muujinaya waxqabadkooda la isku halayn karo, jawaabta taabashada saxda ah, iyo tayada adag ee gaarka ah.
1. Baaxadda Alaabooyinka caadiga ah (1.3 "ilaa 65")
Waxaan bixinaa xalal taabasho IC ah oo leh taageero adag oo loogu talagalay codsiyo badan oo warshadeed, oo ay ku buuxiyeen adeegyo khaas ah iyo kuwo gaar ah. Xalalkayada taabashada waxay taageeraan:
• Taabo hawlgalka oo ay biyo joogaan
• Ku taabo galoofyada ka samaysan dhammaan noocyada agabka
• Ku taabo galaas dabool leh oo dhumucdiisu tahay ilaa 20mm
2. Lagu kalsoonaan karo, Sare{1}Alaabaha Waxqabadka:
Alaabtayadu waxay ka kooban yihiin tayo xasiloon, adeeg nolol dheer, iyo wax qabad heersare ah oo ka soo horjeeda-faragelinta Iyadoo ay taageerayaan koox farsamo oo xoog leh, waxaan bixinaa xulashooyin kala duwan oo badeecado ah, oo ay ku jiraan looxyada kantaroolayaasha la habeeyey iyo qaybaha qaab-dhismeedka birta, si loo buuxiyo shuruudaha gaarka ah ee mashruucaaga.
3. Shaashada Taabashada & Muujinta Awoodaha Wax-soo-saarka
Xarumaha Waxsoosaarka Sare
Waxaan leenahay qolalka nadiifka ah ee Class 1000 & Class 100, iyo sidoo kale qaybinta tooska ah iyo semi{2}} khadadka wax soo saarka ee isku xidhka indhaha ee tooska ah. Xarumahani waxa ay awood noo siinayaan in aan bixino habab otomaatig ah oo buuxa oo loogu talagalay shaashadaha taabashada iyo bandhigyada.
Ma jeclaan lahayd in aan kuwan ku daro mid kali ah oo isku xidhan
Su'aalaha Inta Badan La Isweydiiyo
Ma bixin kartaa adeegga OEM?
-
Haa, waxaan bixinaa adeegyada OEM iyo ODM labadaba waxaanan ku habeyn karnaa alaabada iyadoo lagu saleynayo sawirada aad bixiso.
Sideen ugu aamini karaa tayada alaabtaada?
+
-
Waxaan leenahay waayo-aragnimo 10 sano ka badan ee warshadaha shaashadda taabashada. Laga soo bilaabo wax iibsiga ilaa keenista alaabta, waxaanu leenahay shaqaale xirfad leh iyo habraacyo looga hortagayo khatarta tayada ee iman karta. Alaabadayada waxaa ansixiyay ROHS.
Waa maxay adeeggaaga iibka kadib-?
+
-
Haddii ay jiraan wax dhibaato ah, waxaad ku heli doontaa jawaabtayada 24 saacadood gudahood. Xalka waxaa si degdeg ah u bixin doona kooxdayada xirfadlayaasha ah iyo kuwa xoogga leh.
Waa maxay amarka ugu yar?
+
-
: Shirkadeena inta badan waxay ka shaqeysaa heshiisyo jumlo ah, laakiin haddii aad ku adkaysato inaad iibsato hal set, ku soo dhawoow inaad muunad ka qaado si aad u hubiso tayada iyo shaqada. marka muunad la xaqiijiyo, waxaan u ogolaan karnaa in yar oo amarro ah (aan xadidnayn) in la geliyo wax soo saarka iyo marka tan la xaqiijiyo, MOQ ayaa loo baahan yahay.
Intee in le'eg ayay tahay wakhtiga dammaanadda alaabtaada?
+
-
Caadi ahaan 1 sano oo dammaanad ah oo aan waxyeello u geysan dadka ficillada sida si xun u isticmaalka. Waxay kuxirantahay alaabooyin kala duwan.
